Product Summary
The M25P128-VMF6TP is a multilevel 128Mbit (16Mbit x 8) Serial Flash Memory, with advanced write protection mechanisms, accessed by a high speed SPI-compatible bus. The memory can be programmed 1 to 256 bytes at a time, using the Page Program instruction. The M25P128-VMF6TP is organized as 64 sectors, each containing 1024 pages. Each page is 256 bytes wide. Thus, the whole memory can be viewed as consisting of 65536 pages, or 16777216 bytes. The whole memory can be erased using the Bulk Erase instruction, or a sector at a time, using the Sector Erase instruction.
Parametrics
Absolute maximum ratings: (1)TSTG, Storage Temperature: -65 to 150 ℃; (2)VIO, Input and Output Voltage (with respect to Ground): -0.5 to 4.0 V;(4)VCC, Supply Voltage: -0.2 to 4.0 V; (5)VESD, Electrostatic Discharge Voltage (Human Body model): -2000 to 2000 V.
Features
Features: (1)128 Mbit of Flash Memory; (2)Page Program (up to 256 Bytes) in 2.5ms (typical); (3)Sector Erase (2Mbit); (4)Bulk Erase (128Mbit); (5)2.7 to 3.6V Single Supply Voltage; (6)SPI Bus Compatible Serial Interface; (7)50MHz Clock Rate (maximum); (8)Electronic Signature: JEDEC Standard Two-Byte Signature(2018h); (9)More than 10000 Erase/Program Cycles per Sector; (10)More than 20-Year Data Retention; (11)Packages: ECOPACK (RoHS compliant).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 M25P128-VMF6TP |
STMicroelectronics |
Flash 128MBIT SERIEL FLASH |
Data Sheet |
Negotiable |
|
||||
 |
M25P128-VMF6TPB |
|
IC FLASH 128MBIT 65NM 3V SO16 |
Data Sheet |
Negotiable |
|
||||
